Key Features:
- Scalable & Flexible:
– Multi-customized modes for diverse scenarios
– Support Multiple power sources
PV, Battery, Diesel generator, and utility
– Compatible with lithium, lead-acid, and GEL batteries - High Yields:
– Output power factor up to 1.0
– 2 times peak power ability
– Dual voltage output - Smart & Reliable
– Support WiFi and GPRS Communication for remote monitoring
– PV keeper platform for local commissioning
– Built-in low-frequency transformer
Product Specifications:
Inverter Output
- Rated Power: 6.0kW
- Surge Rating: 18kW
- Inverter Efficiency(Peak): >85%
- Transfer Time 10ms( max )
AC Input
- Voltage: 240VAC
- Max Charging Current: 60A
Solar Charger
- Maximum PV Charge Current: 80A
- Maximum PV Array Power: 5.0kW
- Maximum PV Array Open Circuit Voltage: 250VDC
- MPPT Range@ Operating Voltage: 60~245VDC
- Maximum Efficiency : >97.5%
GENERAL DATA
- Dimensions(W*H*D): 14.17/21.26/8.58 inches( 360*650*218mm)
- Weight: 114.6lbs (52kg)
- Installation: Indoor, Wall-mount
- Protection Degree: IP20
